IInk SDK Web REST Math recognizer examples
Writing a formula
Considering this request body.
rest-math2-example.json
{
"scaleX": 0.265,
"scaleY": 0.265,
"contentType": "Math",
"strokes": [
{
"p": [
1,
0.83,
0.68,
0.73,
0.72,
0.75,
0.74,
0.72,
0.73,
0.74,
0.81,
0.64,
0.58,
0.6,
0.64,
0.68,
0.75,
0.79,
0.73,
0.76,
0.78,
0.77,
0.74,
0.68,
0.68,
0.77,
0.79,
0.74
],
"t": [
1720100156746,
1720100156839,
1720100156856,
1720100156889,
1720100156922,
1720100156938,
1720100156956,
1720100156972,
1720100156989,
1720100157006,
1720100157022,
1720100157039,
1720100157055,
// Open the file to see the full content (1,853 lines)
The strokes of this request correspond to that writing:
The application/x-latex recognition output will give you the following result:
\int_{a}^{b} f ' \left( x \right) d x = f \left( b \right) - f \left( a \right)
You can then use this output to insert the formula in your documents:
